Hard Frame Solar Panel
iTechWorld 200W Hard Frame Solar Panel 22V
A 200W hard frame solar panel with HPX PRO cells and a tough Raptor Skin coating. Just 17mm thick and IP67 rated, it suits roof and external mounting on caravans, 4WDs and boats. Designed and developed in Australia by iTechWorld.
✓ 200W Output✓ 17mm Thin Profile✓ IP67 Waterproof✓ Shade Tolerant
-
✓HPX PRO technology
Reduces power loss from shading and lifts output per square metre -
✓Suits all battery types
Works with 12V lithium and AGM batteries via a charge controller -
✓Powers your 12V gear
Ideal for 12V fridges, LED lighting and water pumps -
✓85cm cable
Pre-attached cable for seamless installation
Slim, Solid And Ready To Mount
At 1460mm by 670mm and only 17mm thick, the 200W panel sits low on a roof or canopy while its hard frame stands up to the weather. Pair it with an MPPT charge controller and a pure sine wave inverter for best results. Mounting brackets are sold separately.
Specifications
- Rated Power200W
- Maximum Voltage18.1V
- Open Circuit Voltage22V
- Short Circuit Current12.2A
- LaminationRaptor Skin coating
- Dimensions1460mm L x 670mm W x 17mm H
- Weight10kg
- Cable Length85cm
- Max System Voltage1000VDC
- Max Series Fuse Rating15A
- Operating Temperature-40°C to 85°C
- Waterproof RatingIP67
- Warranty1 year
Frequently Asked Questions
What can this panel power?
It suits 12V fridges, LED lighting, water pumps and charging off-grid batteries through a solar charge controller.
Which batteries and inverters does it suit?
It works with 12V lithium and AGM batteries. Use an MPPT charge controller and a pure sine wave inverter for best performance.
Is it weatherproof?
Yes. The IP67 rating protects against dust and water immersion.
How do I clean it?
Clean it regularly with a microfibre cloth and avoid harsh chemicals.
